5T Truck-mounted crane
| Technical parameters | |||||
| Lifting capacity | 5T 11M | ||||
| Working radius | Maximum radius | 11 | |||
| Maximum radius | 4.3 | ||||
| Lifting height | Above ground level | 3 | |||
| Below ground level | 40 | ||||
| Design wind speed | Working | 20 | |||
| Non-working | 45 | ||||
| Machinery room tail radius | R<4.78m | Power supply | 380V 50Hz | ||
| Hoisting mechanism | Translation mechanism | ||||
| Hoisting speed | 45m/min | Average translation speed | 33.6m/min | ||
| Motor | Model | YZR250M2-8 | Motor | Model | YZR200L-8 |
| Duty rating | M5 | Duty rating | M5 | ||
| Power | 37kW | Power | 15kW | ||
| Wheel speed | 720r.p.m | Wheel speed | 720r.p.m | ||
| Wheel-rail mechanism | |||||
| Wheel-rail speed | 1.5r.p.m | ||||
| Motor | Model | YZR180L-8 | |||
| Duty rating | M5 | ||||
| Power | 11kW | ||||
| Wheel speed | 720r.p.m | ||||
| Crane installed power capacity | 100kW | ||||
| Hoisting wire rope | 4V3PS+5FC-1770-18 | ||||
| Crane self-weight | 45t | ||||
